EQUIPMENT
VERTICAL MILLS
HAAS VF-2 SS
2020 Haas VF-2ss
5 Axis
Travel X 30” Y 16”
Fanuc Robot
LR Mate 2--iD
HAAS VF-3 SSYT
We have two Haas CNC Vertical Mills
VF-3 SSYT – 5 Axis Simultaneously
Travel X 40” Y 26” Z 25
MAZAK VERTICAL NEXUS 430A
MAZAK VNC 430A Vertical Mill
Table size 35" x 17", w/ 40 Taper Spindle
12,000 RPM
MAZAK VTC-20B & 20C
Mazak CNC Vertical Mill VTC-20C
Travel X 65” Y 20” Z 20”
Mazak CNC Vertical Mill VTC-20B
Travel X 44” Y 20” Z 20”
MAZAK V-655/60 & 80
Mazak CNC Vertical Mill V-655/60
Travel X 58” Y 24” Z 26” – w/50 Taper
Mazak CNC Vertical Mill V-655/80
Travel X 78” Y 24” Z 26” – w/50 Taper
HORIZONTAL MILL
MAZAK HCN-6000 HORIZONTAL
Mazak HNC-6000
Travel X 32” Y 32” Z 32”
Smooth G control
Pallet changer
LATHES
TSUGAMI B0326-III SWISS LATHE
38mm Capability
12' LNS Bar feeder
OKUMA LB4000 EXII MY LATHE
26.38 Swing, 16.93 Max turn Dia.
Live tooling with Y-axis
4” through spindle
LNS Bar feeder
MAZAK QT250-MY
26.60 swing ,14.75 machining diameter, 40.358 machining length, 3 inch bar capability
Live tooling with y-axis
Smooth G control
LNS bar feeder
MAZAK QT250-MSY
27.4 swing ,13.4 machining diameter, 23.5 machining length, 3 inch bar capability
Live tooling with y-axis
Sub-spindle
Smooth G control
LNS bar feeder
MAZAK SUPER QUICK TURN 250 MY
18” Swing, 12” Max turn Dia.
2.5” through spindle
Live Tooling with Y-axis
MOLD ROOM
MAZAK VERTICAL NEXUS 430A
MAZAK VNC 430A Graphite Mill
Table size 35" x 17", w/ 40 Taper Spindle
12,000 RPM
CHARMILLES ROBOFORM 55P EDM
Our sinker EDM includes C axis and a drop tank able to handle work pieces 47.24” x 30.51” and a Z travel of 17.72”. Along with Erowa positioning throughout the process to ensure accuracy and repeatability, we can handle your project both large and small.
MITSUBISHI EA8 SINKER EDM
Our MITSUBISHI EDM includes C axis and a drop tank. Along with Erowa positioning throughout the process to ensure accuracy and repeatability.
MITSUI MSG-250MH
CHEVALIER SUPER-618
Working surface of table 8 x 19
Table to spindle center 20”
Longitudinal table travel 20”
Cross travel 10”
Spindle Speed 3400 RPM
Equipped with Walker Electromagnetic Chuck with Walker chuck control
Sony Magnascale DRO with .0001” readout
Coolant pump and tank for wet grinding
Our manual grinder includes the precision .000050 vertical micro feed. With linear ball bearings and hardened and ground guideways, this grinder is capable of parallelism within .000080” and surface finishes finer than (or equal to) Rmax .3S (3 microinch AA)
VISION LWI IV FLEXX LASER WELDER
Whether your welding requests are mold damage repair or customer revision, our laser welder has the ability to adjust to all of your needs. With a full service and experienced tool room, Osseo Precision Machining can repair your mold from start to finish.
QUALITY
Keyence XM Measuring System
+/- .0003 Tolerance
-GD&T
-Inspection Reports
-Reverse Engineering CAD Package
Other Equipment:
Jet Knee Mill w/Digital Readout
DoAll C-5A Self Feeding Horizontal Band Saw
MillerMatic 252 Wire Feed Welder
Victor Thermal Dynamic Plasma Cutter
Jet Vertical Band Saw 18 3/8" Throat
Software:
MasterCam
Autodesk Inventor HSM Pro 2020
CimatronE 14 Mold Design Software
